Home > Stainless Steel 317/317L Washers
Request For Our Latest Prices On SS 317/317L Washers in Doha, Qatar!
Welcome to the world of Murad Fasteners, your go-to source for top-notch Stainless Steel 317/317L Washers right here in Doha, Qatar. We pride ourselves on delivering high-quality fastening components that can tackle even the toughest industrial challenges. With a reputation built on precision manufacturing, rigorous quality control, and adherence to international standards, we cater to a variety of sectors, including oil and gas, chemical processing, petrochemicals, marine, and power generation. Our Stainless Steel 317/317L Washers are designed to offer exceptional corrosion resistance, durability, and effective load distribution, ensuring that your bolted assemblies are well-protected and have a longer service life, even in harsh, chloride-rich environments.
When it comes to the composition and mechanical properties of our Stainless Steel 317/317L Washers, they are crafted from austenitic stainless steel that boasts a high content of chromium, nickel, and molybdenum. This unique blend significantly enhances their resistance to pitting and crevice corrosion. The 317L grade, with its low carbon content, not only improves weldability but also minimizes carbide precipitation. These washers are known for their impressive tensile strength, toughness, and ductility, all while maintaining stability in moderate to high temperatures. They are built to perform reliably in corrosive and high-pressure settings, ensuring they deliver long-lasting mechanical performance.
| Grade | C | Mn | Si | P | S | Cr | Ni | Mo | N |
| SS 317 | 0.08 max. | 2.00 max. | 1.00 max. | 0.045 max. | 0.03 max. | 18.0 – 20.0 | 11.0 – 14.0 | 3.0 – 4.0 | – |
| SS 317L | 0.03 max. | 2.00 max. | 0.75 max. | 0.045 max. | 0.03 max. | 18.0 – 20.0 | 11.0 – 15.0 | 3.0 – 4.0 | 0.1 |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 317 | 620 MPa | 275 MPa | 45% | 85 | 193 |
| 317L | 595 MPa | 260 MPa | 55% | 85 | 200 |
|
Material |
Specification |
Standards |
Size
|
Length |
|
Stainless Steel 317 / 317L Washers
|
IS
BS
ASTM
|
ASTM / ASME – A/ SA 193 |
3 mm
to
200 mm
|
M02 to M33
|
To satisfy our clients needs by providing high quality products at competitive price as per the schedule and to maintain long term relationship with our clients.
In terms of uses and applications, our Stainless Steel 317/317L Washers are essential for distributing loads and preventing surface damage in bolted assemblies, especially in harsh environments. You’ll find them commonly used in chemical processing equipment, oil and gas pipelines, flanged joints, pressure vessels, and marine installations. They also play a vital role in heat exchangers, power plants, and the pulp and paper industries. Thanks to their outstanding corrosion resistance and durability, these washers are perfect for applications in chloride-rich or acidic environments, providing secure, long-lasting, and dependable fastening solutions.
We ensure the highest quality for our Stainless Steel 317/317L Washers through rigorous testing, including Hardness, Chemical Analysis, Positive Material Identification (PMI), Flattening, Micro and Macro Tests, Pitting Resistance, Flaring, and Intergranular Corrosion (IGC) Tests. Each product is accompanied by detailed documentation, such as a commercial invoice, packaging list, Certificate of Origin, and a Guarantee Letter. Third Party Inspection Certificates are also provided to affirm our commitment to industry-leading standards.
Murad Fasteners is a leading manufacturer and supplier of high-quality fasteners in Doha, Qatar, with over 8 years of experience serving global industries.
